When your operations demand unwavering reliability and precise flow regulation, our Bw Ends Forged Steel Globe Valve is the definitive choice. Engineered from high-grade forged steel, this valve is built to perform in the most demanding industrial environments, ensuring exceptional strength and a long service life.
Key Features & Benefits
This valve’s design delivers a powerful combination of precision and resilience, making it ideal for applications where accurate throttling and reliable shutoff are non-negotiable.
- Exceptional Durability: Crafted with precision forging techniques, the high-quality steel construction offers superior resistance to wear and corrosion, ensuring robust performance in challenging conditions.
- Precision Flow Control: The integral globe valve design features a movable disc that allows for fine-tuned regulation of fluid flow, from accurate throttling to complete isolation.
- Optimal Sealing: A swivel disc and lapped seat faces provide a smooth finish and superior sealing, extending the valve’s life and minimizing maintenance.
- User-Friendly Operation: Whether equipped with a handwheel, gearbox, or electric actuator, the valve offers easy manual or automated control, ensuring seamless integration into your system.
- Robust & Secure Design: The two-piece gland design ensures optimal alignment and uniform packing compression, while the back seat sealing structure provides an extra layer of security.
Built to Industry Standards
Our valves are meticulously manufactured to meet or exceed the most stringent industry standards, guaranteeing quality and performance you can trust.
Wall Thickness: BS1873 / API603 / ASME B16.34
Design & Ratings: ASME B16.34, API 602, BS1873 / API623
End to End Dimensions: ASME B16.10
Flange & Butt Weld: ASME B16.5, ASME B16.25
Materials & Testing: ASTM (Materials), API 598 (Pressure Testing)
Product Specifications
Body Material: A105
Nominal Diameter: 1/2" to 2 1/2"
Pressure Range: Class 150 to 2500 (PN10-PN420)
End Connection: RF, RTJ, BW
Working Temperature: -29℃ to 560℃
Operation: Handwheel, Gear Box, Electric Actuator, etc.
For specialized requirements, including alternate materials, auxiliary connections, or NACE service, please contact us. Our Forged Steel Globe Valves are trusted components in the oil and gas, chemical processing, and power generation industries.
